Box Column Drill Machine

Box Column Drill Machine
Box Column Drill Machine
Product Code : 12
Product Description

 Box Column Drill Machine

Empowered with our prime motto to offer nonpareil quality products to clients in a committed time frame, we have become a superior manufacturer, exporter and supplier of a huge gamut of Box Column Drill Machine. These machines are broadly demanded in several industries such as electrical,automotive, construction, heavy and light engineering industry. Our range of Box Column Drill Machine is known for various significant attributes like higher performance, sturdy construction, durable, longer functional life and the likes.

Specification (All Dimensions are in mm)

Model

KBC 540

Drill Capacity in steel (60kg/mm2)

50

Drill Capacity in cast iron

60

Drill Capacity in steel

M 39

Drill Capacity in cast iron

M 48

Morse taper in spindle

MT 15

spindle traverse on vertical

280

Vertical adjustment of spindle head

280

Distance between spindle and upright

355

Number Spendil Speed

12

Range of Spindle Speed (rpm)

32 - 1400

Number of Power Feeds

9

Range of Feeds (mm/rev)

0.11-1.73

Power of main motor

5/7.5HP, 720/1440 rpm 415V, AC, 3 Ph, 50 Hz

Power of elevating motor

1 HP, 1440 rpm, 415V, AC, 3 Ph, 50

Table


Table With Coolant Gutter

650 x 780

Working Surface

500 x 630

No. of 'T' slots

3

Width of 'T' slots

18

Distance between 'T' slots

160

Max. Distance between spindle& table

750

Base


Base with Coolant Gutter

1150 x 630

Working Surface

490 x 530

No. of 'T' slots

2

Width of 'T' slots

18

Distance between 'T' slots

315

Max. Distance between spindle& table

1200

Space Occupied (L x B x H)

1600 x 7700 x 30001

Net Weight

1700 Kg.
