Crankshaft Grinder Machine

Crankshaft Grinder Machine
Crankshaft Grinder Machine
Product Code : 21
Product Description
As a well known manufacturer, supplier and exporter, we are engaged in offering wide assortment of Crankshaft Grinder Machine. The offered equipment has extensive applications in engineering, construction and automobile industries. Convenient to install, this Crankshaft Grinder Machine is preferred by our large clientele for its availability in tailor made specifications, efficient functioning, rigid construction and so on. This machine is ideal for grinding crankshaft pins and journals.

MODEL No.

PCS-1000

PCS-1500

PCS-2000

PCS-2250

Max.grinding length (with Chucks)

1050

1370

2050

2200

Max.grinding length (with Centers)

1100

1425

2100

2250

Height of centers over table

240

270

300

350

Max. swing over table

480

540

600

700

Max. grinding diam. with new wheel

320

320

250

250

Max. diameter admitted on steady rests

150

150

175

175

Max. weight admitted between centers

175

200

250

250

Max. weight admitted with steady rests

350

450

500

5500

Workheads

Max. head offset

90

115

140

170

Diameter of self centering chucks

150

200

200

250

Workheads rotation speed

27-42-65

27-42-65

27-42-65

27-42-65

Max. quill stroke (on tailstock)

70

70

70

70

Wheelhead

Max. diameter of grindwheel

660

710

760

815

Standard grindwheel thickness

20

20

20

20

Max. grinding wheel thickness

50

50

50

50

 Motors Power

Grinding wheel motor power

5

5

7.5

7.5

Headstock spindle motor power

0,75

1

1,5

2

Coolant unit motor power

0,10

0,10

0,10

0,10

 Overall Dimensions

Work space required

4550 x 1800

5800 x 2000

7000 x 2250

7200 x 2350

Nett Weight

3000

4000

5000

5500

Gross Weight

3500

4700

6000

6200

Box Size & shipping space

3250 x 1850

3850 x 2050

4500 x 2200

4750 x 2300

 Standard Equipment

  • 2 pieces of self centering chucks
  • Arbor equipped wheel balancing stand for maintenance of static balance
  • Compact design
  • Grinding wheel designed with side, face and radius dresser
  • V-gauge for center alignment of cranks
  • Diamond dresser
  • Service kit that consists of hexagon wrench set, oil cane and spanner
  • Flange mounted grinding wheel
  • Dial gauge
  • Coolant fluid collection system and electro pump equipped decantation tank
  • Grinding wheel extractor to safeguard its threaded hub

Optional Equipment

  • Easy to carry super finisher with grinding belt
  • Sizing gauge
  • Rod equipped shaft and centers for center alignment purpose
  • Diameter indicator
  • Wheel head with fast traverse system
  • Automatic movement of its gear box equipped main slide
  • Diving dog with 70mm to 140mm diameter
  • The fluid collection system of its coolant and cleaning tank are designed with magnetic roll and electro pump
