Crankshaft Grinder Machine

Crankshaft Grinder Machine
Crankshaft Grinder Machine
Product Code : 50
Product Description

In the international markets, our company is known as the topnotch manufacturer and exporter of Crankshaft Grinder Machine. The machine is specially engineered and developed for grinding a variety of metals in workshops. We offer this Crankshaft Grinder Machine to clients in different configurations and specifications to meet their individual requirements. Our team uses high grade materials to manufacture this machine.

Features:

  • High operational fluency
  • Low power consumption
  • Long working life

Specifications:

MODEL No.

PCS-1000

PCS-1500

PCS-2000

PCS-2250

Max.grinding length (with Chucks)

1050

1370

2050

2200

Max.grinding length (with Centers)

1100

1425

2100

2250

Height of centers over table

240

270

300

350

Max. swing over table

480

540

600

700

Max. grinding diam. with new wheel

320

320

250

250

Max. diameter admitted on steady rests

150

150

175

175

Max. weight admitted between centers

175

200

250

250

Max. weight admitted with steady rests

350

450

500

5500

Workheads

Max. head offset

90

115

140

170

Diameter of self centering chucks

150

200

200

250

Workheads rotation speed

27-42-65

27-42-65

27-42-65

27-42-65

Max. quill stroke (on tailstock)

70

70

70

70

 Wheelhead

Max. diameter of grindwheel

660

710

760

815

Standard grindwheel thickness

20

20

20

20

Max. grinding wheel thickness

50

50

50

50

Motors Power

Grinding wheel motor power

5

5

7.5

7.5

Headstock spindle motor power

0,75

1

1,5

2

Coolant unit motor power

0,10

0,10

0,10

0,10

Overall Dimensions

Work space required

4550 x 1800

5800 x 2000

7000 x 2250

7200 x 2350

Nett Weight

3000

4000

5000

5500

Gross Weight

3500

4700

6000

6200

Box Size & shipping space

3250 x 1850

3850 x 2050

4500 x 2200

4750 x 2300

Standard Equipment

  • Self centering chuck (2 Pcs.)
  • Wheel balancing stand with arbor (For Static balancing)
  • Steady rest.
  • Grinding wheel face, side and radius dresser.
  • Cranks centering V-gauge.
  • Diamond dresser.
  • Service kit. (oil cane, spanner, hexagon wrench set)
  • Grinding wheel mounted with flenge.
  • Dial guage.
  • Coolant fluid collection and decantation tank complete with electropump.
  • Grinding wheel extractor for threaded hub protection.

Optional Equipment

  • Portable super-finisher with grinding belt.
  • Sizing gauge.
  • Centering device for shaft and centers with rod.
  • Dia indicator
  • Wheel head rapid traverse.
  • Main slide automatic movement with gear box.
  • Diving dog capacity diam. 70 to 140 mm.
  • Coolant fluid collection and cleaning tank, complete with electropump and magnetic roll.
