Drill Machine Kpd-25

Drill Machine Kpd-25
Drill Machine Kpd-25
Product Code : 64
Product Description

Founded in the year 2003, we are considered as one of the leading manufacturers and exporters of Drill Machine KPD-25. The machine is primarily engineered for drilling metals in workshop industry. Manufactured in accordance with industry standards using high quality materials, this Drill Machine KPD-25 is offered to clients at affordable price.

Features:

  • Excellent drilling capacity
  • Occupies less floor space
  • Easy installation and maintenance

Specification (All Dimensions are in mm)

SPECIFICATION

Description



Model No.

KPD - 25


Drilling Capacity

25 mm


Taper in spindle bore

MT - 3


Spindle Travel

252 mm


No of Spindle Speed

8


Range of Spindle Speed

79 - 1968 RPM


Distance between spindle centre to column face

250 mm


Max. distance from spindle nose to base plate

1056 mm


Max. distance from spindle nose to work table

568 mm


Working surface table size

320 x 330 mm


No of slot (Round / Square)

4 / 2


Table travel

315 mm


Diameter of column

87 mm


Height of column

1465 mm


Base Size (Machined area)

323 x 320 mm


Total table size (Max.)

427 x 624 mm


V-Belt section

B - 52


Weight of machine (Approx)

240 kgs.


Recommended electric motor & speed

1 HP, 1440 RPM


Recommended power supply AC

3 Ph., 415+ 10%, 50 Hz


Power factor

0.7 to 0.8


Floor space occupied (LxBxH)

33 x 19 x 74 inch
