Heavy Duty Lathe Machine

Heavy Duty Lathe Machine
Heavy Duty Lathe Machine
Product Code : HDLM 03
Brand Name : HARI OM REFRACTORIES
Product Description

Welcome to ESS Kay Lathe & Machine Tools, world's leading lathe machine manufacturer,supplier & exporter company...

!!! One Place for Lathe Machine, We Provide Complete Solution for Lathe Machine!!!

Heavy Duty Lathe Machine

We are determined to manufacture, supply and export a superior quality range of Lathe Machine like Heavy Duty Lathe Machine. Manufactured by using premium quality steel, castings and utilizing latest technology, these machines are also checked by our experts on different quality parameters to make sure their international quality standards. This Heavy Duty Lathe Machine finds application in diverse engineering industries for wood turning and metal spinning applications.

Products Features

  • Sturdy Construction
  • Compact Size
  • Maintenance Free
  • Simple Installation
  • High Efficiency And Energy Saving Of More Than 30%
  • User friendly design
  • Operational efficiency
  • Low maintenance cost

TECHNICAL DATA AND SPECIFICATIONS FOR STANDARD MODEL KGH-215

(All Dimensions in m.m.)

Centre Height over flat bed ways

:

215 m.m..


Swing Over Bed

:

423 m.m.


Swing Over Cross Slide

:

250 m.m.


Swing in Gap

:

620 m.m.


Length of Gap in front of Face Plate

:

277 m.m.


MODEL

ADMIT BETWEEN CENTRES

LENGTH OF BED

Floor Space Occupied (m.m.)

Aprox.Weight in Kgs.

Aprox.Case Dimensions (m.m.)






Net

Gross


KGH-1

450 m.m.

1370m.m. (4"-6")

1650x970

775

825

2000x1000x1500

KGH-2

725 m.m.

1600m.m. (5"-3")

1950x970

850

900

2200x1000x1500

KGH-3

950 m.m.

1830m.m. (6")

2100x970

875

925

2500x1000x1500

MAIN SPINDLE :

* Type of Spindle Nose

:

Threaded


* Spindle bore

:

38 m.m.

* Spindle Morse Taper

:

MT - 5




* Spindle Speeds Nos./RPM/Range

:

8

54, 90, 140, 224 RPM
315, 500, 775, 1200 RPM

* Spindle Mounting on

:

Taper Roller Bearings

TAIL STOCK SPINDLE : Diameter / 50.8m.m. / Travel:145m.m. / Morse Taper: MT-4

LEADING SCREW : Diameter / Threads : 25.4m.m. / 4 TPI

THREADS





Nos. of Threads / Range

For FullyNorton Gearbox

Metric

:

17 / 0.5m.m. To 15 m.m. Pitch

Inch

:

40 / 2 to 60 TPI


STANDARD ACCESSORIES

OPTIONAL ACCESSORIES

Flame Hardened ways,
Chuck back plate 1 no, centre adapter, Dead centres 2 nos, Tool Post Spanner, Motor pulley, Thread dial indicator, Change gear set-1 (For metric and inch both) and Norton gearbox.

Face plate, Carrier plate, steedy rest, follow rest, Taper turning attachment, motorised coolant pump with tank and fittings, Rear tool post with extended cross slide, chuck back plates (Extra), and Electricals (Motor, Panel Board, Wirings, Push button Switches, V-belts and fittings), Electricals Switch shaft and chip guard.
