Precision Shaper Machine

Precision Shaper Machine
Precision Shaper Machine
Product Code : 27
Product Description

Backed with the support of technical team, we are manufacturing and exporting a wide range of Precision Shaper Machine. The machine is demanded in workshops of industries for shaping various types of metals. We use advanced technology and superior grade raw materials to manufacture the Precision Shaper Machine in accordance with industry standards.

Products Key Features:

  • Robust construction
  • Quick installation
  • Long working life

Shaper Machine ES

Model

ES-18

ES- 24

ES- 30

ES- 36

ES- 42

A-Capacity

450

600

750

900

1050

Length of Ram Stroke

475 mm

610 mm

762 mm

915 mm

1070 mm

Length of Ram

960

1232

1410

1651

2108

Length of Width Ram Bearing

700 x 270

867 x 300

1020 x 330

1130 x 330

1600 x 330

Max. & Min. Distance






From Table of Ram

360x 75

450 x76

510 x75

565x 102

600x 102

B-TABLE

Working Surface of Table

457 x 305

610 x 370

762 x 390

915 x457

1078x 533

Max. Table Travel Horizontal

488

635

787

940

1075

Max. Table Travel-Vertical

330

380

450

525

585

Angular Movement of Table






on Either Slides

60 L 60 R

60 L 60 R

60 L 60 R

60 L 60 R

60 L 60 R

C-TABLE

(Max Vertical Travel of Tool Slide)

152

190

203

255

300

Maximum Swivel of Tool Head

60 L 60 R

60 L 60 R

60 L 60 R

60 L 60 R

60 L 60 R

E-SPEEDS & FEEDS

Dia of Clutch Pulley

311

311

311

380

380

Range of Ram Speeds

4

4

4

4

4

(Stroke Per Minute)

16,32,64,96

14,28,42,62

8,16,32,48

10,20,30,50

8,16,32,48

Dia of Motor Pulley

70

70

76

88

88

Range of Table Feed Per






Stroke of Ram

0.220

0.229

0.229

0-22 To 0-88

0-22 To 0-88

Range of Tool Head Feed

hand feed

hand feed

hand feed

hand feed

hand feed

Automatic Tool Head Feed &






Tool Lifting

on order

on order

on order

on order

on order

F-DRIVE ELECTRICAL EQUIPMENT

Power Supply

2HP(1.5kw)

3HP(2.25kw)

5HP(3.75kw)

7.55HP(5kw)

10HP(7.5kw)

Speed Rpm

1440 RMP

1440 RPM

960 RPM

960 RPM

960 RPM

Main Switch Starter (Push Botton Type)

3.5 AMP

5 AMP

5 AMP

5 AMP

3.5 AMP

Weight (approx.)

1200 kgs.

1850 kgs.

2300 kgs.

3500 kgs.

4000 kgs.

Standard Accessories

  • Automatic Lubricant Pump
  • Swiveling Vice
  • Crank Handle
  • Motor Pulley

Extra Accessories

  • Key way cutting attachment
  • Automatic tool lifting device
  • Automatic feed to the tool side
  • Rapid Feed system with control panel
  • Allen key set
  • V- Belts
  • Screw Driver
  • Electric Motor & Starter with Fitting & Wirings
  • Spanner Set
  • Oil Can
  • Tool Box
